High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production

High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production

  • High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production
  • High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production
  • High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production
High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production
Ürün ayrıntıları:
Menşe yeri: ÇİN
Marka adı: Dupont
Sertifika: CE
Model numarası: Integratec ™ XP 77 IG (eski adıyla SFP 2880XP)
Belge: UF-IntegraTec-P-Series-PVDF...49.pdf
Ödeme & teslimat koşulları:
Min sipariş miktarı: 1 PC
Fiyat: Anlaşılabilir
Ambalaj bilgileri: Standart İhracat Paketleme
Teslim süresi: 5- 8 iş günü
Ödeme koşulları: Western Union, T/T
Yetenek temini: Ayda 60000 adet
İletişim
Tüm ürünler
Aydınlatma Dağıtım Kutusu (33)
Elektrik Dağıtım kutusu (33)
Hava Koşullarına Dayanıklı Dağıtım Kutusu (48)
Fiberglas Muhafaza Kutusu (60)
ATS Otomatik Transfer Anahtarı (68)
EDI modülleri (139)
Ultrafiltrasyon Membran Modülleri (57)
Endüstriyel Devre Kesici (85)
güneş pv sistemi (72)
Elektrikli EV Şarj İstasyonu (21)
Modüler Zamanlama Röleleri (12)
Otomasyon Kontrol Röleleri (64)
Voltaj Regülatörü Trafosu (16)
Film Aydınlatma Balonları (136)
Ay balon ışığı (131)
Tripod LED Balonları (115)
Şişme Işık Kulesi (62)
Terminal Bloğu Aksesuarları (6)
Detaylı ürün tanımı
XP 77 IG Etkili Membran Alanı: 8 inç Modül başına XP 77 IG akış hızı: 2.0–8.5 m³/saat (8.8-37.6 gpm)
XP 77 IG maks besleme basıncı: 20 ° C'de 6.25 bar (90.65 psi) XP 77 XP 77 IG'nin INGUMinal Gözenek Çapı: 0.03 um
XP 77 IG Max Back Wash Baskısı: 2.5 bar (36 psi) Maks. Bu modülün TMP'sini Çalıştırma: 2.1 Bar
Bu modülün maksimum çalışma hava ovma akışı: 12 nm3/saat XP 77 IG Kullanımı: Büyük ölçekli su arıtma
XP 77 IG Adavantage: Yüksek iltihap

High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production

Featuring exceptional fouling resistance and stable high-flux performance, the DuPont IntegraTec XP 77 IG ultrafiltration membrane delivers reliable water purification for critical industrial applications. This advanced membrane provides excellent removal rates for bacteria, viruses, and endotoxins while maintaining low energy consumption and minimal maintenance requirements.

Ideal for pharmaceutical manufacturing, microelectronics production, and healthcare water systems, this membrane ensures compliance with stringent quality standards while offering sustainable operation with reduced chemical usage and wastewater generation.

Product Specifications
Attribute Value
Effective membrane area 8 inch
Flow rate per module 2.0–8.5 m³/hr (8.8–37.6 gpm)
Max feed pressure 6.25 bar (90.65 psi) at 20°C
Nominal pore diameter 0.03 µm
Max backwash pressure 2.5 bar (36 psi)
Max operating TMP 2.1 bar
Max operating air scour flow 12 nm3/hr
NaOCl (max.) 2,000 mg/L
Certifications ISO 9001, NSF, CE
Application Pharma and Beverage
Product Description

The DuPont IntegraTec XP 77 IG ultrafiltration module delivers industry-leading performance for demanding industrial water treatment applications. Engineered with advanced PVDF hollow-fiber technology, it combines exceptional filtration efficiency with robust durability to reduce operational costs and system footprint.

Key Features
  • Superior Filtration Efficiency
    • 0.03 µm nominal pore size: Effectively removes bacteria, viruses, colloids, and particulates
    • High-flux design: 35% higher permeability than previous-generation modules
  • Robust Construction & Reliability
    • PVDF hollow-fiber membrane: Exceptional mechanical strength and chemical resistance (pH 2-11)
    • U-PVC housing: Eliminates the need for external pressure vessels
  • Optimized Operational Economics
    • Outside-in flow configuration: Tolerates feedwater with high suspended solids
    • Innovative end-cap design: Simplifies piping and saves space
High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production 0
Technical Specifications
Model Type Membrane Area (m²/ft²) Module Volume (Liters/Gallons) Weight (Kg/lbs)
XP77 IG Industrial 77 / 829 39 / 10.3 61/100 (empty)
135/220 (water filled)
XP77 NSF/ANSI 61 and 419 77 / 829 39 / 10.3 61/100 (empty)
135/220 (water filled)
High Efficiency · Energy Saving: DuPont XP 77 IG UF Membrane for Pure Water Production 1
Operating Parameters
Parameter SI Units US Units
Filtrate Flux @ 25ºC 40-110 l/m2/hr 24-65 gfd
Flow range 2.0 - 8.5 m3/hr 8.8 - 37.4 gpm
Temperature 1-40ºC 34-104ºF
Max. inlet module pressure (@ 20ºC) 6.25 bar 90.65 psi
Max. operating TMP 2.1 bar 30.5 psi
Max operating air scour flow 12 nm3/hr 7.1 scfm
Max backwash pressure 2.5 bar 36 psi
Operating pH 2-11
NaOCl (max.) 2,000 mg/L
Particle size (max.) 300 µm
Flow configuration Outside in, dead end flow

For application cases, please visit: www.fgwater.com/Industries/

About FG Water Technologies

FG Water Technologies (www.fgwater.com) is now an organic part of Wuxi Fenigal Science and Technology Co. Ltd., which is a high-tech entity integrating water treatment equipment design, manufacturing, trading and shipment served for main industrial sectors.

Our main products include a variety of water purification and treatment equipment, such as seawater reverse osmosis (SWRO) system, brackish water reverse osmosis (BWRO), ultrafiltration (UF) system, Electrodeionization/EDI equipment, media pressure filters and ion exchanger softeners.
