DuPont™ SFP-2880 UF Membrane: Advanced Water Purification for Industrial Applications

Ürün ayrıntıları:

Menşe yeri:	ÇİN
Marka adı:	Dupont
Sertifika:	CE
Model numarası:	SFP-2880
Belge:	Model SFP-2860, SFD 2860, S...80.pdf

Ödeme & teslimat koşulları:

Min sipariş miktarı:	1 PC
Fiyat:	Anlaşılabilir
Ambalaj bilgileri:	Standart İhracat Paketleme
Teslim süresi:	5- 8 iş günü
Ödeme koşulları:	Western Union, T/T
Yetenek temini:	Ayda 60000 adet

İletişim

Tüm ürünler

Aydınlatma Dağıtım Kutusu (33)

Elektrik Dağıtım kutusu (33)

Hava Koşullarına Dayanıklı Dağıtım Kutusu (48)

Fiberglas Muhafaza Kutusu (60)

ATS Otomatik Transfer Anahtarı (68)

EDI modülleri (139)

Ultrafiltrasyon Membran Modülleri (57)

Endüstriyel Devre Kesici (85)

güneş pv sistemi (72)

Elektrikli EV Şarj İstasyonu (21)

Modüler Zamanlama Röleleri (12)

Otomasyon Kontrol Röleleri (64)

Voltaj Regülatörü Trafosu (16)

Film Aydınlatma Balonları (136)

Ay balon ışığı (131)

Tripod LED Balonları (115)

Şişme Işık Kulesi (62)

Terminal Bloğu Aksesuarları (6)

Detaylı ürün tanımı

2880 Modül Akış Aralığı:	3.1 - 9.3 m3 /saat	2880 Modül Membran Alanı:	77 m²
2880 modül nominal gözenek çapı:	0.03 um	2880 Modül Çekirdek Malzeme:	PVDF
Bu modelin 2880 modül filtrat akısı:	40-120	Bu modelin çapı:	8 inç
Ürün akışı yön ayarları:	Dış basınç yapısı, çıkmaz filtreleme	Ürün maks. TMP'yi işletme:	2.1 Bar
Kullanım:	Yüzey suyu, deniz suyu, içme suyu	Adavtage:	Büyük akı

DuPont™ SFP-2880 UF Membrane: Advanced Water Purification for Industrial Applications

Product Overview

Engineered for excellence, the DuPont™ SFP-2880 ultrafiltration membrane represents cutting-edge water treatment technology. This premium-grade membrane utilizes state-of-the-art hollow fiber design to achieve exceptional filtration performance, effectively removing contaminants including pathogens, colloids, and particulate matter.

Specifically developed for demanding industrial environments, it serves as an ideal pretreatment solution for reverse osmosis systems and enables efficient wastewater recycling. The membrane demonstrates outstanding chemical compatibility and mechanical durability, ensuring stable operation under challenging conditions.

Key Features

Advanced Filtration Performance: Removes bacteria, viruses, and colloids with high efficiency; achieves filtrate turbidity below 0.1 NTU and SDI under 2.5; ideal protection for reverse osmosis systems
Engineered Durability: Chemical-resistant PVDF membrane withstands extreme pH conditions; U-PVC housing eliminates need for pressure vessels; operating temperature range supports global deployments
High-Efficiency Design: Industry-leading membrane area enables high flow rates; outside-in flow handles high solids loading; reduced backwash frequency lowers water consumption
Operational Reliability: Consistent performance in municipal and industrial settings; minimal maintenance requirements; compatible with automated control systems

Technical Specifications

Attribute	Value
UF Module Flux Range	40–90 LMH (24–53 gfd) at 25°C
Flow Rate per Module	2.0–6.9 m³/hr (8.8–30.4 gpm)
UF Module Temperature Limits	1–40°C (34–104°F)
UF Module Max Operating TMP	2.1 bar (30.5 psi)
Chemical Tolerance	Withstands up to 2,000 mg/L NaOCl
Membrane Area	77m²
Membrane Type	Industrial Grade Ultrafiltration Membrane Components

Product Specifications

Model	Type	Part #	Membrane Area (m²/ft²)	Volume (Liters/Gallons)	Weight (Kg/lbs)
SFP-2880	Pretreatment	280934	77 / 829	39 / 10.3	61 / 135 (empty), 100 / 220 (water filled)
SFD-2880	NSF/ANSI 61 Drinking water	324169	77 / 829	39 / 10.3	61 / 135 (empty), 100 / 220 (water filled)

Operating Parameters

Parameter	SI Units	US Units
Filtrate Flux @ 25ºC	40-120 l/m²/hr	24-70 gfd
Flow range	3.1-9.3 m³/hr	13.6 - 40.9 gpm
Temperature	1-40ºC	34-104ºF
Max. inlet module pressure (@ 20ºC)	6.25 bar	93.75 psi
Max. operating TMP	2.1 bar	30 psi
Max operating air scour flow	12 nm³/hr	7.1 scfm
Max backwash pressure	2.5 bar	36 psi
Operating pH	2-11

Important: If operating limits and guidelines given in this bulletin are not strictly followed, the limited warranty will be null and void. To prevent biological growth during system shutdowns, it is recommended that preservative solution be injected into the membrane modules.
